HOME >> Power Distributor >> Pro 8 Way 20A American Edison Plug 12 Road 19pin Output Power Distro
  • Pro 8 Way 20A American Edison Plug 12 Road 19pin Output Power Distro
    Pro 8 Way 20A American Edison Plug 12 Road 19pin Output Power Distro
    Pro 8 Way 20A American Edison Plug 12 Road 19pin Output Power Distro
    ❤ Add to collection

  • Pro 8 Way 20A American Edison Plug 12 Road 19pin Output Power Distro

    Place of Origin: Guangdong, China

    Brand Name: NWIITC

    Model Number: BPDC13

    Rated Voltage: three phase

    Rated Current: 400A

    Product Name: Pro 8 way 20A American Edison plug 12 road 19pin output power distro

    Power supply: three-phase five-wire system AC220V±10%, frequency 50Hz/60Hz±5%

    Input current: self-locking 400A rhino plug; reverse output 400A

    Output: 19pin (220V)*8pcs+(110V)*4pcs, Edsio*4Pcs (110V)+4 Pcs (220V)

    Color: black

    • ￥0
      ￥0.00
      ￥0.00
      ￥0.00

    • Satisfaction：

      Sales： 0

      Review： 0

    Weight：0.000KG
    • Quantity：
Description

Place of Origin: Guangdong, China

Brand Name: NWIITC

Model Number: BPDC13

Rated Voltage: three phase

Rated Current: 400A

Product Name: Pro 8 way 20A American Edison plug 12 road 19pin output power distro

Power supply: three-phase five-wire system AC220V±10%, frequency 50Hz/60Hz±5%

Input current: self-locking 400A rhino plug; reverse output 400A

Output: 19pin (220V)*8pcs+(110V)*4pcs, Edsio*4Pcs (110V)+4 Pcs (220V)

Color: black

Pro 8 way 20A American Edison plug 12 road 19pin output power distro

Product Description
Product name:Pro 8 way 20A American Edison plug 12 road 19pin output power distro
Power supply: three-phase five-wire system AC220V±10%, frequency 50Hz/60Hz±5%
Input current: self-locking 400A rhino plug; reverse output 400A
Display: With three-phase A.B.C direct-reading independent liquid crystal current and voltmeter display, various data can be monitored in real time without switching
Output:

8pcs 220V Socapex output,

4pcs 110V Socapex output,

4pcs 220V Edsion output,

4pcs 110V Edsion ouput

Body: using exquisite and durable double-layer shockproof hexagonal board
Control system: the main control adopts 250A main air switch; each independent separate air switch is C20A, with overload and short circuit double protection
Normal working environment:
Ambient temperature: 0-±45C
Relative humidity: 40%-80%
Equipped with LED blue light work light
Size: 68*62*120cm
Gross weight: 103kg



More details of our Pro 8 way 20A American Edison plug 12 road 19pin output power distro as below:

Pro 8 way 20A American Edison plug 12 road 19pin output power distro
