How to Backup Fixture Settings Before Touring
Source: | Author:佚名 | Published time: 2025-07-15 | 219 Views | 🔊 Click to read aloud ❚❚ ▶ | Share:

Why Fixture Backup Matters More Than Ever

Touring environments are unpredictable. Venues vary, power surges happen, and gear sometimes malfunctions or gets reset. That’s why backing up your fixture settings before hitting the road is not optional—it's critical. Whether you're a lighting technician, production manager, or LD overseeing a full rig, ensuring that all DMX addresses, user-defined macros, and custom calibration profiles are securely saved can save hours of reprogramming on-site.

In many real-world cases, venues require quick setups with minimal rehearsal time. A lighting backup gives you a digital parachute, allowing you to restore entire show states in minutes, not hours.


What Can Be Backed Up?

Modern lighting fixtures, especially intelligent ones, store a variety of data. Common parameters you can and should back up include:

  • DMX address and mode (8-bit, 16-bit, extended, etc.)

  • User-defined color presets

  • Focus and zoom positions

  • Pan/tilt limits and speed settings

  • Fixture macros and sequences

  • Custom dimming curves

  • Calibration and white balance settings

  • Fixture-specific behaviors like fan control or auto modes

Knowing what’s stored onboard—and what needs to be restored externally—is step one in forming a reliable backup strategy.


Methods of Backing Up Fixture Settings

1. Onboard Fixture Save to USB

Many modern fixtures feature a built-in USB port that lets you export settings to a flash drive. This is the fastest and most self-contained method—especially useful when your control desk isn’t available or your rig is decentralized.

Steps:

  • Insert FAT32-formatted USB stick.

  • Navigate to fixture menu → “Setup” or “System” → “Export Config.”

  • Label the file clearly (e.g., FOH_LED01_Preset1.bin).

2. DMX Console Backup

If you're using a lighting desk like MA, Avolites, or ChamSys, you can often save fixture-specific parameters as part of the showfile. Some desks allow per-fixture backups as a separate utility.

Tip: Save presets at both the desk level and fixture level. Desks may also save color, beam, and position palettes tied to fixture profiles.

3. RDM-Based Management

Using RDM (Remote Device Management) protocols, you can remotely query and store fixture settings from your lighting controller or RDM hub.

This is especially useful if:

  • You have multiple of the same fixture and want consistent settings.

  • You’re replacing a unit mid-tour and want to copy its profile.

4. Companion Software Tools

Many manufacturers (e.g., Elation, Chauvet, Martin) offer proprietary PC or mobile apps that let you connect via USB, Wi-Fi, or DMX to manage fixture libraries and export settings.

These apps are often:

  • Fixture-specific or family-specific

  • Able to batch export/import settings

  • Useful for syncing across fixtures of the same model


Backup Best Practices for Touring

  1. Label Everything Clearly
    Use consistent naming: TOUR2025_LED1_FOH.dmx. Label by function, model, location.

  2. Use Versioning
    Save different stages: Pre-programming, Post-Focus, Final Tech Rehearsal.

  3. Cloud + Physical Backup
    Sync files to Google Drive, Dropbox, or iCloud, but also bring a USB drive and SD card.

  4. Bring the Fixture Manual
    Even the best backups may need manual adjustment. Having the fixture’s DMX chart and calibration guide on hand can save you in case of hard resets.

  5. Test Your Restore Process
    Backups are only good if you know how to restore them. Simulate a failure and try loading your saved profiles at least once before touring.


How to Handle Fixture Swaps on Tour

If one unit fails and you have to swap in a new fixture mid-tour, here’s what to do:

  • Ensure the replacement is the same firmware version (or close).

  • Match the DMX address and mode exactly.

  • Use USB or desk restore to import saved settings.

  • Re-calibrate position, dimming curve, and pan/tilt range.

  • Check the beam output manually.

This ensures the replacement looks and behaves like the original, preserving cue integrity.


Post-Tour Archiving and Reset

After your tour:

  • Archive all fixture config files in a dated folder (Tour_2025_April).

  • Reset fixtures to factory default before repurposing them for another event.

  • Make a backup of the entire showfile and any updated fixture settings post-tour, in case you return to the same setup.
